Product Details:
Payment & Shipping Terms:
|
| Impedence: | 50Ohm | Length: | 38mm Max |
|---|---|---|---|
| Diameter: | φ14.6 | Frequency Range: | DC-18GHz |
| Housing: | Black Anodize | Note: | Cylindrical Resistor |
| Highlight: | SMA Male RF Coax Termination,DC-18GHz SMA Terminator,10 Watts RF Termination Load |
||
SMA-Male Termination Features a Frequency Range of DC-18GHz with an Average Power Rating of 10watts
Terminations or loads, offered by Xi‘an Elite Electronic are matched to 50Ohms characteristic impedance. Matched loads provide a termination designed to absorb all the incident power with very little reflection, effectively terminating the line or port in its characteristic impedance. Terminations are used in a wide variety of measurement systems; any port of a multi-port microwave device that is not involved in the measurement should be terminated in its characteristic impedance in order to ensure an accurate measurement. Terminations are also used in devices such as directional couplers and isolators.
| Model No. | SMA-JR-10W |
| Power | 10W |
| Frequency Range | DC-18GHz |
| VSWR | ≤1.2 |
| Note | Cylindrical Resistor |
Details of 50Ohm SMA Male RF CoaxTermination 10watt Power DC-18GHz Cylindrical Resistor Load
Advantage :
* High Reliable
* Good Mechanical Performance
* Wide Frequency Range from DC to 18GHz
Applications :
Shipping Service:
The shipment will be delivered via major global expresses, such as DHL, UPS, FedEx etc. Currently, it will be sent out from Xi'an, China.
